SECTION 2 - TURNTABLE
164
1200SJP/1350SJP
3121208
FIGURE 2-21. ENGINE TRAY JACK INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0272064
Ref
ENGINE TRAY JACK INSTALLATION (DEUTZ BF4M2011
ENGINE & TD2011 ENGINES MACHINES)
C
1
0641406
1
Bolt 1/4in-20NC x 3/4in (Prior to SN 0300070646)
2
0641608
4
Bolt 3/8in-16NC x 1in
3
0641818
2
Bolt 1/2in-13NC x 2-1/4in
4
0962051
2
Bearing, Flanged
5
1380147
1
Clip, Spring
6
2840016
1
Jack and Handle Assembly
6A
Ref
Handle Options:
6A
7016374
1
Burr Manufacturing Brand (identified by 4in handle offset)
6A
7024598
1
Hammerblow Corp Brand (identified by 4-1/2in handle offset)
6B
7016322
1
Wiper (Burr Manufacturing Brand Only)
7
3310601
2
Nut #6-32NC
8
3311405
1
Locknut 1/4in-20NC (Prior to SN 0300070646)
9
3311605
4
Locknut 3/8in-16NC
10
3311805
2
Locknut 1/2in-13NC
11
3422530
1
Pin, Hitch (Includes Chain and Cotter Pin) (Prior to SN
0300070646)
12
3430816
1
Pin, Clevis
13
3450404
1
Pin, Cotter 1/8in x 1in
14
3537445
1
Bracket
15
3573454
2
Bracket
16
3910608
2
Screw #6-32NC x 1/2in
17
4711600
8
Flatwasher 3/8in Thin
18
4711800
4
Flatwasher 1/2in Thin
19
4750600
2
Flatwasher #6 Regular
20
4751400
2
Flatwasher 1/4in Regular (Prior to SN 0300070646)
21
4770600
2
Starwasher #6
22
4891800
1
Flatwasher, 1/2in Hardened
Ref
ENGINE TRAY JACK INSTALLATION (DEUTZ TCD2.9L4
ENGINE AND CATERPILLAR ENGINE MACHINES)
1001143294
Ref
Deutz TCD2.9L4 Engine Machines
A
1001135661
Ref
Caterpillar Engine Machines
A
101
0641509
3
Bolt 5/16in-18NC x 1-1/8in
102
0641608
4
Bolt 3/8in-16NC x 1in
103
0641816
2
Bolt 1/2in-13NC x 2in
104
0962051
2
Bearing, Flanged
105
1380147
1
Clip, Spring
106
2840016
1
Jack and Handle Assembly
106A
Ref
Handle Options:
106A
7016374
1
Burr Manufacturing Brand (identified by 4in handle offset)
106A
7024598
1
Hammerblow Corp Brand (identified by 4-1/2in handle offset)
106B
7016322
1
Wiper (Burr Manufacturing Brand Only)
107
3310601
2
Nut #6-32NC
108
3311505
3
Locknut 5/16in-18NC
109
3311605
4
Locknut 3/8in-16NC
110
3311805
2
Locknut 1/2in-13NC
111
3430816
1
Pin, Clevis
112
3450404
1
Pin, Cotter 1/8in x 1in
113
3910608
2
Screw #6-32NC x 1/2in
