SECTION 1 - MACHINE SPECIFICATIONS
3121231 – JLG Lift – 1-3
Platform Size
Oversized Standard - 26 in.- W x 28 in.- L (66cm x 71cm)
Stockpicker - 28 in.- W x 48 in.- L (71cm x 122cm)
Extendible - 26 in.- W x 49 in.- L (66cm x 124cm)
Plat. w/Mat’l Tray - 27 in.- W x 23 in.- L (68cm x 58cm)
Plat. w/Folding Tray - 26 in.- W x 30 in.- L (66cm x 76cm)
Machine Height (platform stowed)
MVL/MSP - 78 in. (198cm) height
Machine Ground Clearance
PHP Retracted - 2 in. (5.1cm)
PHP Extended - 0.75 in. (1.9cm)
Base Footprint
MVL/MSP - 29.25 in.- W x 52 in.- L (74cm) x (132cm)
Table 1-2. 15MVL/MSP - Machine Maximum Wheel Loads (Lb.) and (PSI) - Per Wheel.
Platform Type
(Loaded to Max.
Capacity)
15MVL 15MSP
Average Maximum Average Maximum
Wheel Load Per Wheel (Lb.) (PSI) Per Wheel Wheel Load Per Wheel (Lb.) (PSI) Per Wheel
Rear Front Rear Front Rear Front Rear Front
22 x 25 SB 865 490 138 252
28 x 26 GW 845 550 128 265
26 x 50 GW 860 515 115 321 860 515 115 321
28 x 48 SP 755 615 117 306
w/Folding Tray 810 565 125 313
NOTE: Platform Types: SB - with Sliding Bar Gate GW - with Gull Wing Gate SP - Stock Picker Platform
Table 1-3. 20MVL/MSP - Machine Maximum Wheel Loads (Lb.) and (PSI) - Per Wheel.
Platform Type
(Loaded to Max.
Capacity)
20MVL 20MSP
Average Maximum Average Maximum
Wheel Load Per Wheel (Lb.) (PSI) Per Wheel Wheel Load Per Wheel (Lb.) (PSI) Per Wheel
Rear Front Rear Front Rear Front Rear Front
22 x 25 SB 855 450 132 250
28 x 26 GW 835 460 121 261
26 x 50 GW 850 480 131 277 850 480 131 259
28 x 48 SP 815 560 120 320
w/Folding Tray 810 565 125 313
NOTE: Platform Types: SB - with Sliding Bar Gate GW - with Gull Wing Gate SP - Stock Picker Platform
