SECTION 4 - CONTROL COMPONENTS
3121231 – JLG Lift – 4-15
Operator Programming Mode - (Level-3)
In the Operator Programming Mode the following items
are shown on the main menu (also see Table 4-1):
• Tilt Sensor
• Program
NOTE: There are two production modules available at this
time, one for North/South American and European
languages, and one for Asian languages. All pro-
grammable items between these modules are identi-
cal with the exception of language selection.
Tilt Sensor
Allows viewing current tilt sensor individual X and Y direc-
tion degree reading.
Program
Allows the Operator to program Level-3 items shown in
Table 4-1 following.
Table 4-1. MVL/MSP Ground Control Module - Field Programmable Settings and Factory Preset.
Level-2: Service Level Settings On LCD Display: YES =
✓
HIGH =
↑
Level-3: Operator Level Settings NO =
✕
LOW =
↓
LEVEL PROGRAMMABLE ITEM FACTORY PRESET SETTING RANGE
2 Back to Main 15/20MVL/MSP Return to Programming Menu
3
Set Language
NOTE: There are two production modules available,
one for North/South American and European
Languages, and one for Asian Languages.
1
1 - English 6 - Italian
2 - German 7 - Swedish
3 - Dutch 8 - Brazilian Portuguese
4 - French 9 - Finnish
5 - Spanish
2
1 - English 3 - Japanese
2 - Chinese
2 Set Maximum Lift Up Speed 100% 0 - 100%
2 Set Maximum Lift Down Speed 100% 0 - 100%
2, 3 Set Sleep Time 5 MINS 0 - 60 MINS
2 Set Polarity Of Left Pot Hole Input 1 2 0 - Disabled / 1 - LOW / 2 - HIGH
2 Set Polarity Of Right Pot Hole Input 2 2 0 - Disabled / 1 - LOW / 2 - HIGH
2 Set Polarity Of Up Limit/Elevation Input HIGH HIGH/LOW
2 Set Polarity Of Charger Inhibit LOW HIGH/LOW
2, 3 Set Polarity Of The Keypad Code LOW HIGH/LOW
2 Set Polarity Of Ancillary Input 1 LOW (a) HIGH/LOW
2 Set Polarity Of Ancillary Input 2 LOW (b) HIGH/LOW
2 Load Sensing (LSS) OFF ON/OFF
2, 3 Enable Detection Of Horn Open Circuit NO YES/NO
2, 3 Enable Detection Of Beacon Open Circuit NO YES/NO
2 Enable Obstruction Sensor System (OSS) NO YES/NO
2 Enable Detection Of Aux. #1 Open Circuit NO YES/NO
2 Enable Detection Of Aux #2 Open Circuit NO YES/NO
3 Forward Alarm Disable NO YES/NO
3 OSS Diagnostic NO YES/NO
2 Zero the On-Board Tilt Sensor NO YES/NO
3 View Tilt Sensor Readings — —
2 Brush Wear Sensor Timer Reset — BLANK/WORN
2 Ancillary 1 Input Inhibit 0 0 - 4
2 Ancillary 2 Input Inhibit 0 0 - 4
