Operation
New Brunswick Innova 40/40R Shaker
English (EN)
23
Parameter name and meanings:
5.4 Changing screens
5.4.1 Screen names and descriptions
There are 6 screens on the display:
Tab. 5-1: Screen names and descriptions
5.4.2 Choose screens
In this example, we are changing from the DISP (display) screen to the SET (setup) screen:
Parameter name Meaning
RPM Shaking speed, in revolutions per minute.
°C Chamber temperature, in degrees Celsius.
HRS Programmed time remaining, in hours.
Screen name
(displayed in
bottom-left corner)
Meaning Description
DISP Display Displays 2 user-selectable parameters and measured values.
Change setpoint values (see
Display Screen on p. 24).
SUMM Summary Displays all parameters, measured values, and setpoints.
Change all parameters, measured values, and setpoints (see
Summary screen on p. 26).
SET Set Set day of the week, set time, enable or mute alarm, lock, or
unlock operating parameters (see
Setup screen on p. 27).
COMM Communication Set the communication mode and baud rate (see RS-232 screen
on p. 29).
CAL Calibration Allows user to enter a temperature offset.
Allows user to calibrate speed (see
Calibrate screen on p. 31).
PROG Program Allows user to set up 1 – 4 programs, each with 1 – 15 steps
(see Programs screen on p. 32).
