Operation
New Brunswick Innova 40/40R Shaker
English (EN)
21
5 Operation
5.1 Overview of operating controls
Abb. 5-1: Front panel of Innova 40/40R Shaker
Fig. 5-1: Front panel of Innova 40/40R Shaker
5.2 Powering on
1. Close the lid.
2. Turn Mains/Power switch to the On position.
The display will come on (briefly displaying product information, and then move into the DISP screen.
An audible alarm will sound.
3. Turn the Control knob to turn alarm off. The audible alarm can be muted (see To mute the audible alarm
on p. 29).
When the shaker begins to operate, the display will track the speed as it accelerates to the last entered
setpoint. The shaking action may be started or stopped by pressing the
Start/Stop switch on the front
panel.
1 Display
LCD
2 Control knob
Used to change screens and select operating
conditions
3 Start/Stop switch
Stops or starts shaker agitation
Activates timer when a using timed run
The shaker will not operate if the lid is open. This is indicated by the lid open icon appearing
in the bottom line of the display (see Fig. 5-2 on p. 22).
3
2 1
