Installation
New Brunswick Innova 40/40R Shaker
English (EN)
17
4 Installation
4.1 Selecting the location
Select the location for the device according to the following criteria:
• Suitable power connection.
• Access to RS-232 port.
• Surface where you place the device must be smooth, sturdy, and able to accommodate 90 kg (200 lb).
• Ambient temp of 10 °C – 35 °C.
• Relative humidity of 20 % – 80 %.
• Surrounding area must be well ventilated.
• Allow 7.6 cm (3 in) around shaker for ventilation.
Ensure there is at least this much space for the Innova 40/40R Shaker:
4.2 Install the platform
The Innova 40/40R Shaker can be used with a variety of New Brunswick platforms that will accept a wide
range of clamps for flasks, test tubes, etc. A platform, which is required for operation, is a separate item,
not included with the shaker assembly (see
Platforms on p. 53).
Tools required (provided):
• Allen key, 4 mm (5/32 in)
A platform must be installed on the device prior to use. To install:
WARNING! Heavy!
 Do not attempt to lift the Innova 40/40R Shaker by yourself.
 Ask for assistance or use suitable equipment when raising or handling the device.
Space requirements Width: 68.6 cm (27 in)
Depth: 83.2 cm (33 in)
Height: 106.7 cm (42 in)
NOTICE! Damage to device!
 Never run shaker without a platform.
