Chapter 6 – Batteries
16 S3010E - 514226-000-ANSI
Figure 6.2 – Battery Charge Indicator
6. The battery charge indicator(LED) changes colour
to show the current charging status.
y
RED = Charging Start (0% - 79% charged)
y
YELLOW = 80%
y
GREEN = 100% Fully Charged.
Note
The above sequence is based on a machine with a low
charge contition, charging sequence may resume at a
different stage depending on battery condition.
7. Unplug the extension cord after the charger turns
itself off or charging LED displays green. Allow the
batteries to cool off after charging.
8. Check the battery water level. Add water to individual
cells only if the plates are exposed. Replace the bat-
tery caps.
Note
Machines can also be supplied with maintenance free
batteries, fluid check will not be necessary on this
type of battery.
Battery Charge Indicator
