Chapter 2 – specifications, Component identification, Front rear front rear – Snorkel S3010E User Manual
Page 7
S3010E - 514226-000-ANSI
3
Chapter 2 – Specifications
Component Identification
Upper Controls
Document Holder
Platform
Scissor Assembly
Drive & Steer Wheels
Component Tray
(Hydraulic Reservoir/Pump/batteries)
Lower Controls &
Battery Charger
Emergency Lowering
Valve
Entry Step
Forklift Pockets
Chassis
Toeboards
Guardrails
Entry Gate
Forklift Pockets
Forklift Pockets
FRONT
REAR
FRONT
REAR
