MAINTENANCE SECTION:
Inspection :
1. Inspect machine for any metal fatigue or wear.
2. Do not use if any cracked welds are found. Cease operation and contact UPRIGHT, if any
defects are found. Refer to UPRIGHT pre-delivery and inspection report for
additional information
3. Check pinned connections on outriggers
4. The outrigger retaining pins are to be removed and each outrigger is to be pulled out of its
transport position. Replace the outrigger in a vertical position so that the outrigger pad
faces down. Replace the security pin from where it was removed with the outrigger in its
extended position. Always replace the spring loaded security pin in each outrigger pin.
5. The outrigger is held in place with a hitch-type pin and a hairpin clip. Do not use if the pin
or clip is missing. Replace before use.
6. Check to see that the deck gate chain is in place. Do not use machine if the chain is missing.
Hydraulics – ATF (Automatic Transmission Fluid)
Mercon/Dexron III
1. Check hoses for any leaks or wear.
2. Check oil level in the reservoir. Oil level should be 5 cm below the top of fill tube when the
lift is fully lowered. Total oil capacity is 0.0114 Kilo liter. Do not overfill as this will result
in fluid discharge from the tank vent plug.
3. Vent plug on cylinder should be free of external debris. Do not use the lift if vent plug on
cylinder is missing. Replace vent plug with factory supplied plug before use.
Scissors Stack
1. Check scissors stack connections for wear.
2. A washer and external snap ring hold stack sections in place. Do not operate the lift if a
snap ring or washer is missing.
3. Scissors stack sections require no lubrication
Battery
Proper battery condition is essential to good machine performance and operational safety.
Improper fluid levels or damaged cables and connections can result in component damage and
hazardous conditions.
Before starting with battery maintenance, put on protective clothing and eyewear.
