3. Be sure that the battery retaining fasteners and cable connections are tight.
4. Inspect the battery charger plug and pigtail for damage or excessive insulation wear.
Replace as required.
5. Connect the battery charger to a properly grounded AC power supply.
6. You can expect a minimum of 35 to 75 complete up and down cycles from your UPRIGHT Lift.
7. Eight hours are required to completely recharge your machine with the onboard automatic
charger
Scissors Lift Arm Wear Pads
Maintaining the scissor arm wear pads is essential to safe machine operation. Continued use
of worn out wear pads may result in component damage and unsafe operating conditions. Apply a thin
layer of dry film lubricant to the area of the chassis where the scissor arm wear pads make
contact.
Electrical Wiring
Maintaining electrical wiring in good condition is essential to safe operation and good
machine performance. Failure to find and replace burnt, chafed, corroded or pinched wires could
result in unsafe operating conditions and may cause component damage.
WARNING: Electrocution hazard. Contact with hot or live circuits could result in
death or serious injury. Remove all rings, watches and other jewelry.
1. Inspect the underside of the chassis for damaged or missing wires.
2. Inspect the following areas for burnt, chafed, corroded and loose wires:
a. Ground control box
b. Scissors arms
c. Platform controls
WARNING: Crushing hazard. Keep hands clear of the safety arm when lowering
the platform.
Inspect the center chassis area and scissor arms for burnt, chafed and pinched cables.
1. Scissor arms
2. Power to platform controls
3. Power to platform wiring
Hydraulic Tank Cap Venting System
A free-breathing hydraulic tank cap is essential for good machine performance and service
life. A dirty or clogged cap may cause the machine to perform poorly. Extremely dirty conditions
may require that the cap be inspected more often.
1. Remove the breather cap from the hydraulic tank
2. Check for proper venting.
