Diagram of auto level and variable height – Snorkel XT24AL-sn10000+ User Manual
Page 21
1/31/2008 -
22
-
the machine will level automatically. If the machine does level, several things could cause the
problem. (See the section “Problems with Machine Leveling.” Page 22)
Diagram of Auto Level and Variable Height
Variable
Height
Raise and
Lower
Controls
Push to
Enable
Button
Platform and
Ground Key
Level
Machine
Button
Emergency
Lowering
Emergency
Stop
Retract Legs
and Override
Button
Outrigger
Lights
Down Light
Alarm
Light
Platform
Overload
Low
Voltage
