40
Battery Charge/Fault Code LED Indicator
On normal power-up and operation this series of LEDs visually indicates the amount of change
left in the batteries.
(+) GREEN LEDs lit indicate maximum charge. •
(-) RED LED’s t indicate minimum charge remaining. •
The number of LEDs lit will change depending on the level of charge in the batteries. •
If battery voltage falls below 16.8 volts a fault condition will occur and the machine will stop
operating. The batteries will need recharged.
NOTE: LED Fault Code indications are in Table 3-3, LCD Display – Operating Fault
Conditions, this section of the manual.
Driving Machine
WARNING
WHEN DRIVING WITH PLATFORM LOWERED, DO NOT ATTEMPT TO DRIVE MACHINE
UP A RAMP (GRADE) OF GREATER THAN TWENTY PER CENT (20%), AS TIPPING
COULD OCCUR.
POINT & GO®
The Joystick can be moved in any direction off center.
Drive Power is applied proportionally the further the Joystick is moved off center.
Enter the platform. 1.
