28
3.5 GROUND CONTROL STATION-OPERATION
(See Figure 3-2.)
Main Power Selector Switch
Set the Main Power Selector Switch to Ground Control Mode at the Ground Control Station
Emergency Stop/Shut Down Button
Brake Release Button
PUSH and RELEASE-TO DISENGAGE Brakes
PUSH and RELEASE AGAIN-TO ENGAGE Brakes
NOTE: The brakes only DISENGAGE (electrically) when the joystick control is moved off
center during driving or are manually DISENGAGED (electrically) using the Brake
Release Button.
If the machine’s batteries are completely depleted of electrical charge the brakes
cannot be released manually.
CAUTION
DO NOT MANUALLY DISENGAGE THE BRAKES UNLESS MACHINE IS SETTING ON A
LEVEL SURFACE OR MACHINE IS FULLY RESTRAINED.
POWER OFF
PUSH IN-To Engage
Emergency Stop POWER ON
TURN CLOCKWISE and RELEASE-To Reset
Emergency Stop
