SYNERGY MFG. 870 INDUSTRIAL WAY, SAN LUIS OBISPO, CA (805) 242-0397

INSTALLATION INSTRUCTIONS

PPM-8200 XJ LONG-ARM SUSPENSION

GENERAL NOTES:

These instructions are also available on our website; www.synergymfg.com. Check the website before

you begin for any updated instructions and additional photos for your reference.

Cutting and grinding of stock control arm brackets is required for installation.

Brackets can be bolted or welded on.

Loosely bolt all hardware in until all bolts have been started, then torque to spec.

This kit is designed to be run at a minimum of 4” of lift and requires the use of a 4” bump stop spacer to
prevent track bar interference at full compression travel.

A Slip Yoke Eliminator kit will likely be needed in the rear for lift heights above 4”

PARTS LIST:

8230– XJ LONG ARM FRAME BRACKET

(1) 823001-L

(1) 823001-R

(2) 823002 XJ Long Arm UCA nut tab

(12) 3/8-16 UNC x 1” long hex head bolt

(12) 3/8-16 UNC Nylock nut

(24) 3/8” flat washer

(4) 3/8-16 UNC x ¾” long thread cutting screw

(4) 9/16-12 UNC x 4” long hex head bolt

(2) 9/16-12 UNC Stover Nut

(6) 9/16” flat washer

(2) 9/16” lock washer

8231– XJ LONG ARM LOWER CONTROL ARM (PAIR)

(1) 8231-01-L Left Lower Control Arm, XJ Long arm (Assembled)

(1) 8231-01-R Right Lower Control Arm, XJ Long Arm (Assembled)

8232– XJ LONG ARM UPPER CONTROL ARM (PAIR)

(1) 8232-01-L Left Lower Control Arm, XJ Long arm (Assembled)

(1) 8232-01-R Right Lower Control Arm, XJ Long Arm (Assembled)

8233– XJ FRONT TRACK BAR BRACKET AND BRACE KIT
