5232 YJ REAR CAGE KIT
Version 1.1
GENERAL NOTES:
• These instructions are also available on our website; www.synergymfg.com.
Check the website before you begin for any updated instructions and additional
photos for your reference.
• This is a weld in roll cage kit, all welding should be performed by an experienced
welder with proper welding equipment
• Use in conjunction with PPM-5231; YJ front cage kit
• This kit works with either a soft top or hard top
• Use extreme care when welding and grinding in the interior of your Jeep, remove
or cover any components you do not want welding spatter or grinding sparks to
damage.
1) Remove the hard or soft top.
2) Remove the roll cage padding / covers and the rear upper seat belt mounting bolts. It
is also a good idea to remove the rear seat to prevent damage from welding and ease
installation.
3) Install the PPM-5231 YJ Front Cage kit per the instructions included with the front
cage kit.
4) Remove the paint on the factory cage around the areas to be welded. Position the C-
pillar cross bar and B-C pillar spreaders as shown below in picture 4.1
