ARB 5611210 User Manual
Page 3
08-10-09
Page 3 of 19
3783146
3131192L
1
End surround LHS
3131192R
1
End surround RHS
6151083
6
Bolt M8 x 35
6151132
6
Nut M8 flange
4581044
6
Washer 8mm flat
FIT END SURROUNDS TO
REAR BAR
6250003
6
Spacer 8mm thick gold zinc
3756757L
1
End surround brace LHS
3756757R
1
End surround brace RHS
6151017
2
Bolt M6 x 20
6151046
2
Washer Flat M6
6151128
2
Nut Flange M6
6151083
4
Bolt M8 x 35
6151021
4
Bolt M8 x 20
6151132
4
Nut M8 flange
4581044
8
Washer 8mm flat
4581046
8
Washer 8mm spring
3199774
1
Wing brace nut plate
FIT END SURROUND
BRACES
6151303
2
Nut M8 cage
3162478L 1
Vertical
trim
3162478R 1
Vertical
trim
3162482L
1
End surround trim
3162482R
1
End surround trim
6821166 2
Reflector
6151162
10
Nut M6 nyloc
FIT URETHANE TRIMS
4581082
10
Washer 6mm flat heavy duty black zinc
3199769
1
Top infill plate
3199727
1
Aluminium step plate
4590019
1
Rubber extrusion seal
FIT TOP INFILL PLATE
6151256
10
Button head cap screw M6 x 16 stainless steel
4761132 1
Gooseneck
55010 1
Pull
pin
FIT GOOSENECK
55020 1
Spring
Clip
FIT TRAILER PLUG
6151370
2
Screw M4 x 20 plastite pan head
PARTS SUPPLIED WITH THIS KIT TO BE USED WHEN FITTING WHEEL CARRIERS OR JERRY CAN CARRIERS
86060BL
1
Number plate light
6151281
2
Screw M5 pan head
FITTING NUMBER PLATE
LIGHT
6151282
2
Nut M5 flange
3756677
1
Centre locator bracket
6151255
2
Bolt M12 x 40 x 1.75
4581049
4
Washer 12mm flat
4581050
2
Washer 12mm spring
FIT CENTRE LOCATOR
6151189
2
Nut M12 x 1.75
TOOLS REQUIRED: Basic tool kit, 30mm socket, ¼” drive socket set, silicon.
TORQUE SETTINGS: 6mm – 9Nm, 8mm – 22Nm, 10mm – 44Nm, 12mm – 77Nm
