35. . The single cut out packers to the front of
the bar. (As viewed from front of vehicle )
When these packers are fitted, tighten all
bolts firmly.
36.
Bend over handles of nut
plates so that struts are
not destroyed when wheel
carriers or jerry can carriers
are closed.
AT THIS STAGE JERRY CAN CARRIERS OR WHEEL CARRIERS MUST BE FITTED.
TO FIT JERRY CAN CARRIERS AND WHEEL CARRIERS, REFER TO FITTING
INSTRUCTIONS SUPPLIED IN FITTING KITS WITH JERRY CAN CARRIERS OR WHEEL
CARRIERS.
IF A JERRY CAN CARRIER OR WHEEL CARRIER IS NOT TO BE FITTED, THE COVER
PANEL SHOULD BE ALREADY FITTED. (REFER TO STEP 16.)
Bend handle over
