ARB 5611210 User Manual
Page 16
08-10-09
Page 16 of 19
3783146
48. Using M8 x 20 bolts, flat washers and
flange nuts secure end surrounds to braces
finger tight. (RHS shown.)
49. Before tightening bolts fit urethane vertical
trim between end plate and end surround.
50.
Adjust trim to fit snugly around the rear bar
and the end surround.
51. Align top face of end surround parallel with
body of vehicle.
52. Starting in the top corner of the end
surround and working backwards tighten all
bolts.
A second person may be required to help
keep the vertical trim fitting snugly and to
ensure the end surround remains parallel
to the body.
VIEWED FROM RHS OF VEHICLE.
