Parts listing – ARB 3462040 User Manual
Page 4
Last Rev Date: 24/7/07
Page 3 of 16
Fitting instructions# 3783176
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
PARTS LISTING
PART
No
QTY
DESCRIPTION
3756785L
1
BRACKET BAR MOUNT LHS
3756785R
1
BRACKET BAR MOUNT RHS
3199796
2
PLATE CAGE NUT
4581049
10
M12 WASHER FLAT
4581050
8
M12 WASHER SPRING
6151255
6
BOLT M12 X 40
6151244 2 BOLT
M12X150
6151189 2 NUT
M12x1.75
6151305
4
NUT M12 CAGE SUIT 4MM
MOUNT BRACKETS TO
VEHICLE
5811037 2 SLEEVE
WINCH 180302
8
CABLE
TIE
6151365
2
EYEBOLT M24 2.5 SWL
6151361
2
NUT M24 GR8 ZP
3756765
2
BRACKET NUT RETAINING
4581300
2
WASHER M24 EYEBOLT
6151046 2 WASHER
M6
6151017
2
BOLT M6 X 16mm
TOW HOOK RELOCATION
6151128
2
NUT FLANGE M6
4581291
2
WASHER M10 BZ
6151321 2 NUT
FLANGED
6151364
2
SCREW CAP M10X30 ZP
3756775
1
BRACKET STD CONTROL BOX IN PAN
CONTROL BOX FITMENT
3199790
1
TRIM PLATE FOR 16500LB CONTROL
6151017
4
BOLT M6 X 16mm
6151128
4
NUT FLANGE M6
6151046 4 WASHER
M6
NUMBER PLATE FITMENT
3751384
1
BRACKET No. PLATE
6151128
2
NUT FLANGE M6
6151256
2
SCREW M6 S/STEEL BUTTON HEAD
6151046 2 WASHER
M6
6191013
1
EXTRUSION WINCH COVER @ 1757
WINCH COVER FITMENT
6522048
1
PANEL WINCH COVER
6131349
1
FRAME ASSY WASHR BOTTLE PROT
6151303
2
NUT CAGED M8 SUIT 1.6-3.2
6151022 2 BOLT
M8X25
4581044
2
WASHER FLAT M8
4581046
2
WASHER SPR M8
6151232 2 BOLT
M10X30
4581040
2
WASHER FLAT M10
WASHER BOTTLE
PROTECTION
4581048
2
WASHER SPR M10
