GENERAL CARE AND MAINTENANCE
By choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products
in the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent
value. To keep your bar in original condition it is important to care and maintain it following these
recommendations:
Prior to exposure to the weather your bar should be treated to a Canuba based polish on all
exposed surfaces. It is recommended that this is performed on a six monthly basis or following
exposure to salt, mud, sand or other contaminants.
As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough
visual inspection of the bar is carried out, making sure that all bolts and other components are
torqued to the correct specification. Also check that all wiring sheaths, connectors, and fittings are
free of damage. Replace any components as necessary. This service can be performed by your
local authorized ARB Stockist.
FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
Metric Spanner and Socket set
Allen key set
Phillips head screwdriver
Dia 5.5, 10.0 and 12.0mm drill bits
Electric drill 13mm chuck
Sikaflex 227 adhesive, black color
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe
work procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE
Torque Nm
Torque lbft
M6 9Nm
4lbft
M8 22Nm
16lbft
M10 44Nm
32lbft
M12 77Nm
57lbft
Note :
• This bull bar is suitable for Warn 12,000-16,500lb winches.
• Fog light provisions are in lower pan area of bull bar. IPF840FYS lights are suitable for
this location.
