Jeep Wrangler JK Full Width Bumper 4 Kit # 83235 / 236
After Completing Installation
Engine Compartment
1. Connect both battery cables. Connect positive cable
first, then negative cable.
Miscellaneous
1. Check all fasteners to ensure they are tight.
2. Ensure all wires are properly connected and there is
ample slack..
WARNING
Retorque all fasteners after 500 miles and after off road
use. All body lift components should be visually
inspected and fasteners retorqued during routine vehi-
cle servicing.
CAUTION
Performance Automotive Group does not recommend
any particular wheel and tire combinations for use with
its products and cannot assume responsibility for the
customer’s choice of wheels and tires. Refer to your
owner's manual for recommended tire sizes and warn-
ings related to the use of oversized tires. Larger wheel
and tire combinations increase stress and wear on
steering and suspension components, which leads to
increased maintenance and higher risk for component
failure. Larger wheel and tire combinations also alter
speedometer calibration, braking effectiveness, center
of gravity, and handling characteristics. Consult an
experienced local off road shop to find what wheel and
tire combinations work best with your vehicle.
NOTE
All warranty information, instruction sheets, and other
documents regarding the installation of this product
must be retained by the vehicle owner. Information
contained in the instructions and on the warranty card
will be required for any warranty claims. The vehicle
owner needs to understand the modifications made to
the vehicle and how they affect vehicle handling and
performance. Failure to provide the customer with this
information can result in damage to the vehicle and
severe personal injury.
Kit Parts List
Qty. Description
1 Bumper
2 D-Rings
1 Hardware Pack
4 Bolt, Button Head (1/2”-13 x 1-1/4”)
8 Bolt, Hex Head (1/4”-20 x 3/4”)
4 Nut, Flange (1/2”-13)
8 Nut, Flange (7/16”-14)
8 Nut, Flange (1/4”-20)
8 Washer, SAE (1/4”-20)
4 Washer, Large “Special”
Copyright 4/12
Performance Automotive Group
www.p-a-g.net
