PARTS
GyroMixer End User Guide 57
PART NO DESCRIPTION NO REQ
A 18301 LEAD SCREW CAP 2
B 18302 KEY, 48 TOOTH GEAR (1/8” X 1/8” X 1/4”) 2
18311 FEMALE CLAMPING PRESSURE PLATE (NOT SHOWN) 1
C 18319 NYLON SPACER (3/8” X 3/4” X 1/8”) 4
D 18343 CLAMPING HANDLE PIN 1
18398 BRASS 72 TOOTH GEAR (NOT SHOWN)
EXPLOSION PROOF GYROMIXER ONLY 2
E 18399 STEEL 48 TOOTH GEAR 2
F 18427 THRUST BUSHING (3/8” ID X 3/4” OD) 4
18428 FLANGE BUSHING, 3/8” ID X 1/2” OD 5/16” (NOT SHOWN)
G 18429 FLANGE BEARING (1/2” ID X 5/18” OD X 1/2”) 1
H 18447 THRUST BUSHING (1/2” ID X 1” OD) 2
18451 BRASS 48 TOOTH GEAR (NOT SHOWN)
EXPLOSION PROOF GYROMIXER ONLY 2
I 20454 RADIAL BALL BEARING (1/2” X 1-1/8:) (NOT SHOWN) 2
21530 GEAR ARM ASSEMBLY(INCLUDES DOWEL PINS) 1
21531 UPPER STATIONARY GEAR ARM ASSEMBLY, COMPLETE,
INCLUDES BEARINGS, BUSHINGS, CLAMPING PRESSURE PLATES,
GEAT ARM ASSEMBLY AND GEARS (NOT SHOWN)
STANDARD GYROMIXER 1
21532 UPPER STATIONARY GEAR ARM ASSEMBLY, COMPLETE,
INCLUDES BEARINGS, BUSHINGS, CLAMPING PRESSURE PLATES,
GEAT ARM ASSEMBLY AND GEARS (NOT SHOWN)
EXPLOSION PROOF GYROMIXER ONLY 1
J 21533 STEEL 72 TOOTH CENTER GEAR WITH TAPPED HOLES,
INCLUDES BUSHINGS 1
K 21534 STEEL 72 TOOTH GEAR WITH BUSHING
(TWO FOR EXPLOSION-PROOF, FOUR FOR STANDARD) 2 / 4
21535 MALE CLAMPING PRESSURE PLATE ASSEMBLY, INCLUDES
BUSHINGS (NOT SHOWN) STANDARD GYROMIXER 1
21536 MALE CLAMPING PRESSURE PLATE ASSEMBLY, INCLUDES
BUSHINGS (NOT SHOWN) EXPLOSION PROOF GYROMIXER ONLY 1
L F0024A3B08 SCREW, FLANGE HEAD CAP (10-32 X 1/2” SOCKET WITH NYLON
PATCH) 6
