SETTING UP THE MIXER
12
OPERATIONAL TEST
1. Verify that the power is connected to the mixer.
2. Open the mixer's sliding door.
3. Slide a container into the groove on the table.
Note: Rotate the clamp handle counter clockwise first to open
the clamp arms.
4. Rotate the bail shield over the container bail. Remove the shield for
containers smaller than one gallon.
Note: Failure to properly position the bail shield on containers
larger than one gallon may damage the mixer.
5. With both hands, turn the knobs on the crank handle clockwise until
snug. Continue turning until the crank handle suddenly slips.
6. Close the sliding door.
7. Set the timer. (Not required for Explosion-Proof model)
Note: Make sure that the emergency stop switch is in the "on"
(pulled out) position. This can be done by turning the
knob counter clockwise.
8. Move the power lever to the ON position. The unit should cycle
automatically with minimum vibration. If vibration of the cabinet
occurs, immediately depress the emergency stop switch.
Note: Vibrations may occur because the unit is not properly
leveled. Try rocking the unit to make sure that all four feet
are solidly contacting the floor. Readjust the feet if
necessary. After the feet have been adjusted, reset the
emergency stop switch and continue.
9. When the test is complete, move the power lever to the OFF position.
10. Open the sliding door.
11. Rotate the mechanism to an upright locking position.
12. Use the knob marked "open" to turn the crank handle in the direction of
the arrow until the container is free. If necessary rotate the bail shield
away from the bail and remove the container.
