PARTS
GyroMixer End User Guide 53
PART NO DESCRIPTION NO REQ
A 01113 SCREW (8-32 X 3/8) 4
B 18310 UPPER MOVING ARM ASSEMBLY, INCLUDES BUSHINGS, SCREWS,
MOVING ARM & UPPER TABLE 1
C 18322 YOKE 1
D 18323 ROD GUIDE 2
E 18324 LEAD SCREW 2
F 18330 LOWER MOVING ARM ASSEMBLY (INCLUDES BUSHINGS, SCREWS,
LOWER MOVING ARM & TABLE) 1
G 18341 PLANE BUSHING (1/2” X 5/8” OD X 5/16”) 1
H 18342 COMPRESION SPRING (0.6 OD, X 1”) 4
I 22876 PIN 1
J 22875 NUT, SLOTTED 1
K 18340 CLAMP HANDLE ASSEMBLY 1
L 18390 LOWER STATIONARY ARM ASSEMBLY 1
M 18420 UPPER STATIONARY CLAMPING GEAR ARM ASSEMBLY, INCLUDES
BEARINGS, BUSHINGS, CLAMPING PRESSURE PLATES, GEAR ARM
ASSEMBLY & GEARS 1
N 18422 GEAR ARM COVER 1
18430 TORSION SPRING (NOT SHOWN) 1
O 25279 RATCHET, CLAMP LOCKING 1
P 18447 THRUST BUSHING (1/2” X 1” OD) 3
Q 18459 PLUG, POLYETHYLENE (2”) 1
21525 LOWER MOVING ARM ASSEMBLY, INCLUDES BEARINGS AND HUB
(NOT SHOWN) 1
21526 CLAMP HANDLE ASSEMBLY, INCLUDES BUSHINGS AND DOWL PIN
(NOT SHOWN) 1
21527 LOCKING LINKAGE KIT, INCLUDES DOWEL PIN, PAWL SCREWS AND
SPRING (NOT SHOWN) 1
R F0103816 SCREW (1/2-13 X 1”) 2
S F0103824 SCREW (1/2-13 X 1-1/2”) 2
F0115A0724 DOWEL PIN (1/2-13 X 1-1/2”) (NOT SHOWN) 2
T F0100A3B08 SCREW (10-24 X 1/2”) 8
U F01260812062 SPACER, 1/2” ID X 3/4” OD X 1/8” 6
