PARTS
GyroMixer End User Guide 51
PART NO DESCRIPTION NO REQ
A 01007 ROLL PIN (3/16 X 1” SS) 2
B 03163 NUT (3/4-10 HEX) 2
C 18334 SHAFT COUPLER (1” HEX) 1
D 18392 SEALED BALL GEARING 1
E 18397 SECONDARY PULLEY 1
F 18456 SECONDARY IDLER SHAFT 2
G 20454 BALL BEARING, R8ZZ (5” ID X 1.125 OD) 2
H 21528 PULLEY HUB ASSEMBLY, INCLUDES ROLL PINS, HUB, PULLEY AND
LOWER ARM 1
I F00101 RETAINING RING, EXTERNAL (. 1”) 2
J F000904 RETAINING RING, EXTERNAL (1.5”) 1
K F001101 RETAINING RING, INTERNAL (80MM) 1
L F0100A4B12 SCREW (1/4-20) 1
M 21529 LOWER STATIONARY ARM ASSEMBLY, INCLUDES BEARINGS AND HUB 1
M 18391 LOWER STATIONARY ARM 1
