PARTS
GyroMixer End User Guide 39
PART NO DESCRIPTION NO REQ
A 18370 INCOMING CORD, 12 FEET; STANDARD GYROMIXER 1
B 18444 MAIN DRIVE POLY-V BELT, 820 J 1
C 118487 IDLER ADJUSTMENT BRACKET 1
D 26458 MOTOR (1 HP, 100-200V/200-240V, 50/60 HZ - 1425/1725 RPM)
STANDARD GYROMIXER 1
D 20824 MOTOR (1 HP, 115/230VAC, 60 HZ - 1425/1725 RPM)
EXPLOSION PROOF GYROMIXER ONLY 1
E 119348 CABINET WIRING HARNESS
STANDARD 100-120V GYROMIXER 1
F 32563 SOLID STATE INTERVAL TIMER 100-120V
STANDARD GYROMIXER 1
F 32564 SOLID STATE INTERVAL TIMER 220-230V
EXPLOSION PROOF GYROMIXER ONLY 1
G 4000096 NUT, HEX (1/4-20, WITH NYLON PATCH)
ANTI-ROTATION ASSEMBLY AND TIMER MOUNTING SCREW
AVAILABLE ONLY IN PACKAGE OF TWELVE - PART NO. S4000438 5
H 5608204 LOW VOLTAGE POWER RELAY
STANDARD AND EXPLOSION PROOF GYROMIXER
NOTE: THE LOW VOLTAGE POWER RELAY IS USED ON 100-120VOLT
EXPLOSION PROOF GYROMIXERS AND MUST BE INSTALLED IN AN
EXPLOSION PROOF BOX. 1
I F0103616 SCREW, HEX SERRATED FLANGE (3/8-16 X 1")
TWO IDLER ADJUSTMENT BRACKET MOUNTING SCREW AND FOUR
MOTOR MOUNTING SCREWS 6
J F01191008 SCREW, HEX SERRATED FLANGE; NO. 10 X 1/2”, WITH NYLON PATCH
ELECTRICAL COVER MOUNTING SCREW 4
20446 ELECTRICAL COVER (NOT SHOWN) 1
