SERVICE
GyroMixer End User Guide 29
11. Perform a motor test:
• Plug in the mixer.
• Turn on the motor and confirm that the rotation of the motor is
clockwise, as viewed from the shaft end.
• If not, refer to the wiring diagram on the side of the motor and
correct the rotation setting.
Note: If the diagram does not specify, the default is as viewed
from the lead end where the power wires are located.
• Unplug the mixer.
12. Replace the belt on the motor pulley and set the belt tension.
Note: The tension on the poly V-belt will fell looser than a
standard V-belt.
13. Plug in the mixer.
14. Test run the mixer for 60 seconds to check the belt tension.
Note: If necessary, unplug the mixer and adjust the tension. This
is also the time to adjust the motor drive pulley, if
required.
15. Reassemble the top cover and the rear access panel.
16. Plug in the mixer.
