9
1/2-20 UNF RH
30
0.596
.47 5/8” HEX
SEAT CORE
WASHER
DEPRESSOR PER ARI 720
+.01/-.035
FROM FACE OF BODY
7/16-20 UNF RH
O-RING
45
torqued into the seat. Appropriate handling is
required to not scratch or dent the surface.
1/2" HEX
This surface provides a metal to metal seal when
o
o
(Part No. EC39EZ067)
C08453
Fig. 9 -- CoreMax Access Port Assembly
EXAMPLE:
Model 580J*14D
Circuit 1:
Outdoor Temperature
85_F (29_C) . . . . . . . . . . . . . . . . . .
Suction Pressure 125 psig (860 kPa) . . . . . . . . . . . . . . . . .
Suction Temperature should be 58_F (14_C) . . . . . . . . . .
Circuit 2:
Outdoor Temperature
85_F (29_C) . . . . . . . . . . . . . . . . . .
Suction Pressure 120 psig (830 kPa) . . . . . . . . . . . . . . . . .
Suction Temperature should be 60_F (16_C) . . . . . . . . . .
580J
