APPENDIX II. PHYSICAL DATA (cont.)
Physical Data
(Heating)
7.5 -- 12.5TONS
580J**08
580J**12
580J**14
Gas Connection
# of Gas Valves
1
1
1
Nat. gas supply line press (in. w.g.)/(PSIG)
4---13 / 0.18---0.47
4---13 / 0.18---0.47
4---13 / 0.18---0.47
LP supply line press (in. w.g.)/(PSIG)
11---13 / 0.40---0.47
11---13 / 0.40---0.47
11---13 / 0.40---0.47
Heat Anticipator Setting (Amps)
1st stage
0.14
0.14
0.14
2nd stage
0.14
0.14
0.14
Natural Gas Heat, Liquid Propane Heat
# of stages / # of burners (total)
1 / 3
2 / 4
2 / 4
LO
W
Connection size
1/2” NPT
3/4” NPT
3/4” NPT
Rollout switch opens / Closes
195 / 115
195 / 115
195 / 115
Temperature rise (min/max)
20 --- 50
25 --- 65
25 --- 65
# of stages / # of burners (total)
2 / 4
2 / 5
2 / 5
MED
Connection size
3/4” NPT
3/4” NPT
3/4” NPT
Rollout switch opens / Closes
195 / 115
195 / 115
195 / 115
Temperature rise (min/max)
35 --- 65
30 --- 65
25 --- 65
# of stages / # of burners (total)
2 / 5
2 / 5
2 / 5
HI
G
H
Connection Size
3/4” NPT
3/4” NPT
3/4” NPT
Rollout switch opens / Closes
195 / 115
195 / 115
195 / 115
Temperature rise (min/max)
45 --- 75
35 --- 70
35 --- 70
580J
