72 Brocade VDX 8770-4 Hardware Reference Manual
53-1002563-02
System size and weight
A
System size and weight
The weight of the Brocade VDX 8770-4 can vary considerably depending on the combination of
modules installed. Use
Table 20 and Table 21 to determine the weight of the Brocade VDX 8770-4
with your combination of modules.
TABLE 19 System architecture
Feature Description
Ethernet Ports Up to 192 ports.
Control Processor Redundant (active/standby) management modules.
Scalability Full fabric architecture: * see the Network OS 3.x Release Notes for the most
up-to-date information.
Brocade ISLs and
Brocade Trunking Interfaces (line card ports) automatically come up as Fabric inter-switch links (Fabric
ISLs) in VCS mode. If ISL formation fails, the interfaces come up as edge ports.
Trunk groups of up to eight ports are supported on the 48x10G line card only.
Media types 1 GbE optical
1 Gb copper SFP
10 GbE optical
10 Gb twinax copper
40 GbE optical
TABLE 20 System size and weight
System Size or weight
Width 43.74 cm (17.22 in.)
Height 34.70 cm (13.66 in.)/8U
40.0 cm (15.75 in./10U) with Intake Duct
Kit
Depth 60.96 cm (24 in.)
66.04 cm (26 in.) with fans
Brocade VDX 8770-4 weight: (fully configured)
192-port configuration with four line cards, including two
management modules, three switch fabric modules, two fans, four
power supplies, and two cable management finger assemblies
86.18 kg (190 lb)
Empty chassis weight: (includes backplane, cables, bus-bars, power
distribution bus, chassis ID card)
•
No management modules
•
No switch fabric modules
•
No line cards
•
No power supplies
•
No fans
•
No cable management devices
31.75 kg (70 lb)
