DISPLAY ZOOM - Combustion test data in the Run/Hold screens can be
shown with enlarged characters to make viewing easier. The complete
list of Run/Hold data can be scrolled through for all zoom levels. Available
zoom levels and information display are as follows:
• Standard - 4 lines of information
• 2X - 3 lines of enlarged characters
• 3X - 2 lines of enlarged characters
STATUS - A status menu displays the instrument software version, boot
version, model number, and serial number.
DIAGNOSTICS - The diagnostics menu displays the O2 sensor life, CO
sensor information, and hours of operation for the instrument and the
pump.
KEYPAD SOUND - Keypad sounds can be enabled or disabled with soft-
ware menu selections.
LOW BATTERY - A tone will sound every 10 seconds when a low battery
condition exists. A low battery message will also be displayed.
AUTOMATIC POWER DOWN - The instrument can be set to automati-
cally power off after a period of inactivity unless the user presses any but-
ton; the CO is greater than 50 ppm, or the O2 is less than 16.0%. Auto-
matic power down can be set for None, 30, or 60 minutes.
PURGE - The sensors will be purged when the instrument is shutdown
until sensor outputs indicate that they have been exposed to fresh air.
Pressing the On/Off key a seconds time can defeat the purge routine. The
minimum purge time can be set to None, 5 seconds, 1 , 5, or 10 minutes.
SENSOR ACCESS - Sensor replacement can be accomplished in the fi eld.
Easy access to the O2 and CO sensors is provided through the back of the
instrument.
POWER - The Fyrite ® INSIGHT is powered by 4 AA alkaline batteries. A
new set of alkaline batteries will provide a minimum of 20 hours of con-
tinuous operation with the pump running and the back light on. Option-
ally, the analyzer can operate with a universal AC adapter. When the AC
adapter is plugged into the unit, batteries do not have to be removed.
1.2 Fyrite ® INSIGHT Features & Benefi ts
AUTOMATIC ZERO - The instrument will automatically zero all sensing
channels on ambient air when it is powered on. If a particular sensor is in
error during warm-up, the instrument will automatically display the error
and continue to operate with the sensor in error. However, all information
dependent on the sensor in error will not be presented.
TEMPERATURE UNITS - Temperatures can be displayed in Centigrade
or Fahrenheit.
PRESSURE UNITS - Pressures can be displayed in milliBar (mB),
Pascal (Pa), hectoPascal (hPa), Millimeters of Water Column (mmwc), or
Inches of Water Column (inwc).
LANGUAGE - The display options are English, French or Spanish.
MEMORY - The Fyrite ® INSIGHT has the ability to store, recall to dis-
play, and print a minimum of 100 sets of time and date coded combustion,
differential pressure, or differential temperature test records.
DOWNLOAD - Test records can be downloaded to a personal computer via
the USB port. Saved records are transferred using PC based software and
will be automatically loaded into an Excel spreadsheet. PC based software
will also have the capability to update the instrument time and date and
upload custom fuels, username, customer logo, and future code updates.
The INSIGHT can also be set up from PC software.
USER INFORMATION - The instrument will accept up to three lines of
20 characters of user information. This information will appear with the
test records when they are printed or downloaded.
CALIBRATION - Calibration can be performed by applying gas and enter-
ing calibration gas concentrations through software menu selections.
SMART SENSORS - B-Smart sensor technology is employed for the CO
channel. CO sensors are calibrated prior to shipment and provide data that
can be entered through the software menu selections for easy calibration
without applying gas.
CALIBRATION REMINDERS - Calibration reminders can be set for
Never, 6, 8, 10, 12, or 15 months.
DISPLAY FORMAT - The Run/Hold display format can be presented in
default or custom ordered for specifi c needs. Up to 8 lines can be custom-
ized in the Run/Hold screen.
