3 Controls & Displays
12
En
1 CD / CD–R / CD–RW – Indicates
the type of disc currently loaded.
2 SKIP ON – Lights to indicate that a
disc contains skip IDs. Blinks when setting
or clearing skip IDs.
3 REC – Lights to indicate recording or
record-pause mode. Blinking display
indicates record muting.
4 RPT / RPT–1 – Lights when disc
repeat / track repeat mode is on.
5 SYNC – Lights when the recorder is in
automatic synchro recording mode.
6 DIGITAL – Lights when the optical
digital input is selected.
7 – Auto track indicator (lights when
automatic track numbering is on)
8 D.VOL – Lights when the digital volume
is set to something other than 0dB.
9 FINALIZE – Lights if the CD-RW
currently loaded has been finalized.
10 PGM – Lights in program-play mode.
11 RDM – Lights in random-play mode.
Display
ATT
WAKE-UP TAPE FINALIZE
D.VOL PGM RDM
RDS CD - RW
SLEEP SYNC DIGITAL
SKIP ON REC RPT-1
1 2 3 4
5 7 9 6 8 10 11
