Connecting the Units
Connecting the system (1)
Yellow
Navigation system (AVIC-X1BT)
hide-away unit (sold separately)
When installing
the Hide-away unit
in the boot, etc.,
the extension cable
(e.g. CD-SC300E)
(sold separately)
is required.
Yellow
IP-BUS cable (supplied)
6 m
Black
STAND ALONE
IP BUS
White (audio output (Left))
Red (audio output (Right))
Yellow (rear video output)
Hide-away unit
This product
25 pin cable (supplied)
Depending on where you install,
this cable is not used.
Black
Black
20 cm
2.7 m
9 cm
Black
Black
Blue
Blue
White
Red
