CHAPTER 4 CONTROL PANEL
4–15
MODE Switch Settings in HP-GL Mode
The following table shows all the selections you can make with the
MODE switch in the HP-GL mode.
✒ Note
The mode menus and settings that can appear vary according to the
current emulation mode, printer status, and any options that may be
installed in the printer.
Mode Menu Setting Menu Sub-Setting Menu Setting
INTERFACE MODE
Same as LaserJet Mode
(See 4-19.)
FORMAT MODE
(See 4-22.)
PAGE FORMAT MODE PAPER=LETTER
(For 110/120V mode)
LETTER, LEGAL, A4, A5,
A6, B5, B6, EXECUTIVE,
COM10, MONARCH, C5,
and DL
X OFFSET= 0 -500 (left) to +500 (right) dots
Y OFFSET= 0 -500 (up) to +500 (down)
dots
exit Exit to PAGE FORMAT
MODE
GRAPHICS MODE PEN SETTING
SETTING PEN1 PEN1 to 6
(Set size and gray
percentage for the selected
pen. )
SIZE #=3 dots 1 to 10 dots (pen size in
dots)
(# is the selected pen
number. )
GRAY #=100% 15, 30, 45, 75, 90, or 100%
(# is the selected pen
number. )
exit Exit to SETTING PEN1–6
exit Exit to GRAPHICS MODE
CHARACTER SET
STANDARD SET Standard character set
ANSI ASCII See character sets on page
4-28.
ALTERNATE SET Alternate character set
ANSI ASCII See character sets on page
4-28.
exit Exit to GRAPHICS MODE
exit Exit to FORMAT MODE
RESOLUTION MODE RESOLUTION RESOLUTION=600 300, 600 or 1200 dpi
(See 4-31.) HRC SETTING HRC=MEDIUM OFF, LIGHT, MEDIUM, or
DARK
exit Exit to RESOLUTION MODE
