CHAPTER 4 CONTROL PANEL
4–1
CHAPTER 4
CONTROL PANEL
DISPLAY AND LAMPS
This printer has one liquid crystal display (LCD) and five lamps on the
control panel. The display can show various messages with up to 16
characters. The lamps light to indicate the current printer status.
Fig. 4-1 Display and Lamps
Alarm Lamp
Ready Lamp
