General view, General view -3 – Brother HL-2060 User Manual
Page 40
CHAPTER 2 GETTING STARTED
2–3
General View
Fig. 2-3 Front View
Fig. 2-4 Rear View
Top Cover
Power Switch
Bi-directional Parallel
Interface Connector
RS-232C Serial
Interface Connector
Adjustment Knob for
Face Up/Down Print Delivery
Modular Jack for Options
Universa Serial
Bus connector
