Olympus E-400 - Manual (Page 147)

147
In
formation
9
Specifications
„ Product type
Product type : Single-lens reflex digital camera with interchangeable
lens system
Lens : Zuiko Digital, Four Thirds System Lens
Lens mount : Four Thirds mount
Equivalent focal length on
a 35 mm film camera
: Approx. twice the focal length of the lens
„ Image pickup device
Product type : 4/3 type CCD (primary color filter)
No. of total pixels : Approx. 11,200,000 pixels
No. of effective pixels : Approx. 10,000,000 pixels
Screen size : 17.3 mm (H) x 13.0 mm (V) (0.7" x 0.5")
Aspect ratio : 1.33 (4:3)
„ Viewfinder
Product type : Eye-level single-lens reflex viewfinder
Field of view : Approx. 95 % (for field of view on recorded images)
Viewfinder magnification : Approx. 0.92x (-1 m
-1
, 50 mm lens, infinity)
Eye point : 14 mm (0.6") from the cover glass (-1 m
-1
)
Diopter adjustment range : -3.0 - +1.0 m
-1
Optical path fraction : Quick return half mirror
Depth of field : Can be checked with the
< button (when PREVIEW
registered)
Focusing
Screen : Fixed
Eyecup : Interchangeable
„ LCD monitor
Product type : 2.5" TFT color LCD (Hyper crystal LCD)
Total no. of pixels : Approx. 215,000 pixels
„ Shutter
Product type : Computerized focal-plane shutter
Shutter : 1/4000 - 60 sec.
Bulb shooting (ISO100 - 400 : 8 min., ISO500 - 800 :
4 min., ISO1000 - 1600 : 2 min.)
„ Auto focus
Product type : TTL phase-contrast detection system
Focusing point : 3-point multiple AF (left, center, right)
AF luminance range : EV 0 - EV 19
Selection of focusing point: Auto, Optional
AF illuminator
: The built-in flash provides light. (Light can also be
provided by an external electronic flash.)
Camera specifications
