4 - Language Dictionary

72

Table 4-8. *RST Settings

CAL:STAT

OFF

[SOUR:]CURR 10% of MAX*

DIG:DATA 0

[SOUR:]CURR:TRIG 10% of MAX*

DISP:STAT

ON

[SOUR:]CURR:PROT:STAT OFF

DISP:MODE

NORM

[SOUR:]LIST:COUN

0

DISP:TEXT ‘ ‘

[SOUR:]VOLT 0

INIT:CONT

OFF

[SOUR:]VOLT:TRIG 0

OUTP

OFF

[SOUR:]VOLT:PROT MAX*

OUTP:DFI

OFF

TRIG:ACQ:COUN:CURR 1

OUTP:DFI:SOUR

OFF

TRIG:ACQ:COUN:VOLT 1

OUTP:PROT:DEL

.08 Norm; .008 Fast

TRIG:ACQ:HYST:CURR 0

OUTP:REL OFF

TRIG:ACQ:HYST:VOLT 0

OUTP:REL:POL

NORM

TRIG:ACQ:LEV:CURR MAX*

SENS:CURR:RANG MAX

TRIG:ACQ:LEV:VOLT MAX*

SENS:CURR:DET ACDC

TRIG:ACQ:SLOP:CURR POS

SENS:FUNC VOLT

TRIG:ACQ:SLOP:VOLT POS

SENS:SWE:OFFS:POIN

0

TRIG:ACQ:SOUR INTERNAL

SENS:SWE:POIN

2048

TRIG:TRAN:SOUR BUS

SENS:SWE:TINT

15.6

µ

s

* Maximum values are model-dependent. Refer to Table 4-3.

*SAV

This command stores the present state of the dc source to the specified location in non-volatile memory.
Up to 4 states can be stored. If a particular state is desired at power-on, it should be stored in location 0. It
will then be automatically recalled at power turn-on if OUTPut:PON:STATe is set to RCL0. *RCL retrieves
instrument states.

Command Syntax

*SAV

Parameters

0 | 1 | 2 | 3

Example

*SAV 3

Related Commands

*RCL *RST

CAUTION:

*SAV causes a write cycle to nonvolatile memory. Nonvolatile memory has a finite
maximum number of write cycles. Programs that repeatedly cause write cycles to
nonvolatile memory can eventually exceed the maximum number of write cycles and
cause the memory to fail.

*TST?

This query causes the to do a self-test and report any errors. 0 indicates that the dc source passed self-
test. 1 indicates that one or more tests failed. Selftest errors are written to the error queue (see Appendix
C).

Query Syntax

TST?

Returned Parameters
