Language Dictionary - 4

63

Table 4-5. Bit Configuration of Questionable Status Registers

Bit Position

15

14

13-11

10

9

8-5

4

3

2

1

0

Bit Name

not

used

Meas

Ovld

not

used

Unreg

RI

not

used

OT

not

used

FS

OCP

OV

Bit Weight

16384

1024

512

16

4

2

1

OV = overvoltage protection has tripped
OCP = overcurrent protection has tripped
FS = the fuse is blown
OT = overtemperature protection has tripped
RI = remote inhibit is active
Unreg = output is unregulated
Meas Ovld = measurement overload

STATus:QUEStionable?

This query returns the value of the Questionable Event register. The Event register is a read-only register
which holds (latches) all events that are passed by the Questionable NTR and/or PTR filter. Reading the
Questionable Event register clears it.

Query Syntax

STATus:QUEStionable[:EVENt]?

Parameters

None

Examples

STAT:QUES? STATUS:QUESTIONABLE:EVENT?

Returned Parameters

(register value)

Related Commands

*CLS STAT:QUES:ENAB
STAT:QUES:NTR STAT:QUES:PTR

STATus:QUEStionable:CONDition?

This query returns the value of the Questionable Condition register. That is a read-only register which
holds the real-time (unlatched) questionable status of the dc source.

Query Syntax

STATus:QUEStionable:CONDition?

Parameters

None

Examples

STAT:QUES:COND? STATUS:QUESTIONABLE:CONDITION?

Returned Parameters

(register value)

STATus:QUEStionable:ENABle

This command and its query set and read the value of the Questionable Enable register. This register is a
mask for enabling specific bits from the Questionable Event register to set the questionable summary bit
(QUES) of the Status Byte register. This bit (bit 3) is the logical OR of all the Questionable Event register
bits that are enabled by the Questionable Status Enable register..

Command Syntax

STATus:QUEStionable:ENABle

Parameters

0 to 32767

Preset Value

0

Examples

STAT:QUES:ENAB 20 STAT:QUES:ENAB 16

Query Syntax

STATus:QUEStionable:ENABle?

Returned Parameters

(register value)

Related Commands

STAT:QUES?
