4 - Language Dictionary
40
Table 4-1. Subsystem Commands Syntax
ABORt Resets the trigger system to the Idle state
CALibrate :
:CURRent
[:SOURce]
[:DC] [:POSitive]
:NEGative
Calibrate positive output current and high current
measurement range
Calibrate negative output current
:MEASure
[:DC] :LOWRange Calibrate low current measurement range
:AC Calibrate ac current measurement circuits
:DATA Input a calibration measurement
:LEVel Advance to next calibration step (P1 | P2)
:PASSword Set calibration password
:SAVE Save new cal constants in non-volatile memory
:STATE [,] Enable or disable calibration mode
:VOLTage
[:DC] Calibrate output voltage and voltage readback
:PROTection Begin voltage protection calibration sequence
DISPlay
[:WINDow]
[:STATe] Enable/disable front panel display
:MODE Set display mode (NORM | TEXT)
:TEXT [:DATA] Sets the text that is displayed
INITiate
[:IMMediate]
:SEQuence[] Initiate a specific numbered sequence (1 | 2)
:NAME Initiate a specific named sequence (TRAN | ACQ)
CONTinuous
:SEQuence1, Set continuous initialization
:NAME TRANsient, Set continuous initialization
MEASure | FETCh
:ARRay
:CURRent [:DC]? Returns the digitized instantaneous current
:VOLTage [:DC]? Returns the digitized instantaneous voltage
[:SCALar]
:CURRent [:DC]? Returns dc current
:ACDC? Returns the total rms current (ac+dc)
:HIGH? Returns the HIGH level of a current pulse
:LOW? Returns the LOW level of a current pulse
:MAX? Returns maximum current
:MIN? Returns minimum current
:VOLTage [:DC]? Returns dc voltage
:ACDC? Returns the total rms voltage (ac+dc)
:HIGH? Returns the HIGH level of a voltage pulse
:LOW? Returns the LOW level of a voltage pulse
:MAX? Returns maximum voltage
:MIN? Returns minimum voltage
