OPERATION
TX235 02/07 Operation Section 4-3
© 2007 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
Cutting Width 284”
Overall Width 287”
Transport Width 142”
Transport Height 129”
Overall Height 37”
Transport Length 198”
Mowing Length 234”
Wing Flex (Degrees) 30 Up/ 20 Down
Cutting Height Range 1” - 4-1/2”
Number of Decks 3, 100” Decks
Blade Tip Speed 16,700 FPM
Blade Overlap 2”
Mower Overlap 8”
Updraft Blades 9, Std.
Blade Dimension 3/8” x 3” x 34-11/16”
Greasable Blade Spindles Std.
Blade Spindle Size (Diameter) 1-3/8”
Spindle Bearing Type Tapered Roller
Banded Belt Drive System Std.
Deck Thickness 3/16”
Side Skirts 3/16” x 6”
Slip Clutch Protection Std.
Main Driveline Cat 4 CV’
Wing Drivelines Cat 3
Transport Wheels 2, 26.00 x 12.00 x 12, 6-Bolt
Transport Wheel Width 86”
Caster Wheels 12, 18.00 x 8.50 x 8
Ground Pressure 4 PSI
The Mower is designed for certain mowing applications and is rated to cut up to a specific
size vegetation (see Mower Standard Equipment and Specifications). DO NOT use this
mower to cut vegetation above the Mower’s rated capacity or to cut any type of non-
vegetative material. Only operate this Mower on a properly sized and equipped Tractor.
Operating this Mower in an application for which it is not designed and/or operating the
Mower with the wrong size Tractor can cause Mower component damage and equipment
failure resulting in possible serious injury or death.
(SGM-14)
