Norgren Super X Series Valves - Manual (Page 9)

Super X Series Valves
All Dimensions in Inches (mm)
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-7-9
03 0293 22
1/8" NPT 3/2 Heavy Duty Roller Lever Actuated
Spring Return Valve
1.50 (38)
2.87 (73)
'12' '2' '10'
'1' '3'
.94 (24)
.98 (25)
1/8 NPT
.31 (8)
1.57 (40)
.22 (6)
Ш.26 (7)
.22 (6)
.04 (1)
.85 (22)
Ш .75 (19)
1.38 (35)
.79 (20) .35 (9)
.67 (17)
.75 (19)
.83 (21)
Operating Force: 4 lbs (18N); Operating Travel: .31" (8 mm)
Over-travel: .04" (1mm)
Cam Angle of Approach: 45° maximum
Cam Speed: 26' (8 m)/min. maximum
Operating Speed: 300 cpm
03 0423 22
1/8" NPT 3/2 Sensitive Roller Lever Actuated
Spring Return Valve
.75 (19)
.39 (10)
‘12’
‘2’
‘3’ ‘1’
1.50 (38)
.39 (10)
.21 (5)
‘10’
.83 (21)
.33 (9)
.12 (3)
.04 (1)
2.56 (65)
.87 (22) 1.42 (36)
2.64 (67)
4.45 (113)
1/8 NPT
1/8 NPT
.35 (9) .67 (17)
.75 (19)
.63 (16)
.71 (18)
Operating Force: .22 lbs (1N)
Constant Bleed Pilot Supply: 30 psi (2 bar) minimum
Pre-travel: .04" (1 mm); Over-travel: .12" (3 mm)
Cam Angle of Approach: 45° maximum
Cam Speed: 21' (6.5 m)/min. maximum
03 0427 22
1/8" NPT 3/2 Roller Lever Actuated Pilot Return
Valve
.75 (19)
.39 (10)
‘12’
‘2’
‘3’ ‘1’
1.50 (38)
.21 (5)
‘10’
.87 (22)
4.13 (105)
.87 (22) 1.42 (36)
1.18 (30)
.83 (21)
.12 (3)
.31 (8)
2.32 (59)
2.13 (54) .94 (24)
1/8 NPT
1/8 NPT
.39 (10)
.75 (19)
.35 (9)
.33 (9)
.63 (16)
Operating Force: 2 lbs (9N), ‘10’ at zero bar
Reset Pressure: 30 lbs (2 bar) minimum
Operating travel: 26' (8 mm); Over-travel: .12" (3 mm)
Cam Angle of Approach: 45° maximum
Cam Speed: 26' (8 m)/min. maximum
Operating Speed: 300 cpm
03 0411 22
1/8" NPT 3/2 Roller Lever Actuated Spring Return Valve
.39 (10)
‘12’
‘2’
‘3’ ‘1’
1.50 (38)
.39 (10)
.21 (5)
‘10’
.67 (17)
3.94 (100)
.87 (22) 1.42 (36)
1.18 (30)
.83 (21)
.35 (9)
.12 (3)
.31 (8)
.75 (19) 2.30 (59)
2.13 (54)
1/8 NPT
.63 (16)
.75 (19) .35 (9)
Operating Force: 4 lbs (18N); Operating Travel: .31" (8 mm)
Over-travel: .12" (3 mm)
Cam Angle of Approach: 45° maximum
Cam Speed: 26' (8 m)/min. maximum
Operating Speed: 300 cpm
