Super X Series Valves
All Dimensions in Inches (mm)
VAL-7-16 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
X3 0640 22
1/4" NPT 5/2 Plunger Actuated Spring Return Valve
‘14’ ‘4’ ‘2’ ‘12’
‘5’ ‘1’ ‘3’
.45 (12) .91 (23)
.26 (7)
2.56 (65)
.91
(23)
1.10 (28)
.28 (7)
.94 (24)
.39 (10)
.31 (8) max.
1.65 (42)
.87 (22)
4.69 (119)
1.18 (30) 1.85 (47)
.87 (22) 1/4 NPT
.45 (12)
.91
(23)
Operating Force: 14 lbs (62N)
The plunger on this valve is designed for axial loading only.
X3 0642 22
1/4" NPT 5/2 Roller Actuated Spring Return Valve
‘14’ ‘4’ ‘2’ ‘12’
‘5’ ‘1’ ‘3’
.45 (12) .91 (23)
.26 (7)
2.56 (65)
.91
(23)
.87 (22)
5.20 (132)
1.18 (30) 1.85 (47)
.87 (22)
.75 (19)
.31 (8)
1.10 (28)
.30 (8) 1/4 NPT
.45 (12)
.91
(23)
Operating Force: 15 lbs (67N)
Cam Angle of Approach: 45° maximum
Cam Speed: 20' (6 m)/min. maximum
Operating Speed: 200 cpm
X3 0649 22
1/4" NPT 5/2 Roller Actuated Pilot Return Valve
‘14’ ‘4’ ‘2’ ‘12’
‘5’ ‘1’ ‘3’
.45 (12) .91 (23)
.26 (7)
2.56 (65)
.91
(23)
.91
(23)
5.51 (140)
1.18 (30) 1.85 (47) .75 (19)
.31 (8)
1.10 (28)
.30 (8)
1/4 NPT
1/8 NPT
.45 (12)
Operating Force: 3 lbs (13N), ‘12’ at zero bar
Reset Pressure: 30 psi (2 bar) minimum
Cam Angle of Approach: 45° maximum
Cam Speed: 20' (6 m)/min. maximum
Operating Speed: 200 cpm
