2-21
Hardware Setup
Important
Before you remove or install any components, make sure the system is not
turned on or connected to the AC power.
System Assembly
Chassis Cover
1.
Unscrew the chassis cover.
2.
S l i d e t h e c h a s s i s c o ve r
backwards.
3.
Lift the chassis cover up to remove it from the chassis.
4.
Follow the above procedures in reverse order to replace the chassis cover if
nec essary.
