MSI P1-109N-L70 User Manual
Page 15
1-7
Getting Started
Graphics
- XGI Z7 graphics controller
Onboard I/O
Front I/O
- 1 serial console port (RJ-45 jack)
- 2 USB 2.0 ports
- 2 NIC fiber LAN ports with link/activity LEDs
- 5 individual RJ-45 Gigabit LAN ports with LEDs
Onboard Connectors
- 1 USB 2.0 connector (2 ports)
- 1 serial port connector
- 1 D-Sub VGA connector
- 1 mouse/keyboard connector
- 1 SPI Flash ROM connector (for debugging)
Slot/Golden Finger
- 1 Mini PCI slot
- 2 PCI Express x4 golden finger
Regulations
- FCC, CE
Dimension
- 239mm X 364.5mm
M ounting
- 9 mounting holes
