Slot / golden finger – MSI P1-109N-L70 User Manual
Page 38
2-18
M S-92A2 Server
Slot / Golden Finger
Important
When adding or removing expansion cards, make sure that you unplug the
power supply first. Meanwhile, read the documentation for the expansion
card to configure any necessary hardware or software settings for the expan-
sion card, such as jumpers, switches or BIOS configuration.
Golden Finger
PCI Express x4
Mini PCI Slot
PCI Express x4
Mini PCI Slot
