CPLD Data Reflash Pinheader:JP1
JP1
1
8
Pin
Description
Pin
Description
1
VCC
2
TDD
3
TDI
4
IspEN
5
TRST
6
TMS
7
GND
8
TCK
Pin Definition
Keyboard/Mouse Connector: J3
This connector is used to connect a mouse/keyboard.
PIN
SIGNAL
1
KBMS_Power
2
KBMS_Power
3
KEY
4
NC
5
GND
6
GND
7
MSCLK
8
KBCLK
9
MSDAT
10
KBDAT
Pin Definition
J3
1
9
2
10
