EP7312
High-Performance, Low-Power System on Chip
Description of the EP7312’s Components, Functionality, and Interfaces
The following sections describe the EP7312 in more detail.
Processor Core - ARM720T
The EP7312 incorporates an ARM 32-bit RISC micro
controller that controls a wide range of on-chip peripherals.
The processor utilizes a three-stage pipeline consisting of
fetch, decode and execute stages. Key features include:
•
ARM (32-bit) and Thumb (16-bit compressed) instruction
sets
•
Enhanced MMU for Microsoft Windows CE and other
operating systems
•
8 KB of 4-way set-associative cache.
•
Translation Look Aside Buffers with 64 Translated Entries
Power Management
The EP7312 is designed for ultra-low-power operation. Its core
operates at only 2.5 V, while its I/O has an operation range of
2.5 V–3.3 V. The device has three basic power states:
• Operating — This state is the full performance state.
All the clocks and peripheral logic are enabled.
• Idle — This state is the same as the Operating State,
except the CPU clock is halted while waiting for an
event such as a key press.
• Standby — This state is equivalent to the computer
being switched off (no display), and the main
oscillator shut down. An event such as a key press
can wake-up the processor.
shows the power management pin assignments.
MaverickKey
™
Unique ID
MaverickKey unique hardware programmed IDs are a solution
to the growing concern over secure web content and
commerce. With Internet security playing an important role in
the delivery of digital media such as books or music,
traditional software methods are quickly becoming unreliable.
The MaverickKey unique IDs provide OEMs with a method of
utilizing specific hardware IDs such as those assigned for
SDMI (Secure Digital Music Initiative) or any other
authentication mechanism.
Both a specific 32-bit ID as well as a 128-bit random ID is
programmed into the EP7312 through the use of laser probing
technology. These IDs can then be used to match secure
copyrighted content with the ID of the target device the
EP7312 is powering, and then deliver the copyrighted
information over a secure connection. In addition, secure
transactions can benefit by also matching device IDs to server
IDs. MaverickKey IDs provide a level of hardware security
required for today’s Internet appliances.
Memory Interfaces
There are two main external memory interfaces. The first one
is the ROM/SRAM/FLASH-style interface that has
programmable wait-state timings and includes burst-mode
capability, with six chip selects decoding six 256 MB sections
of addressable space. For maximum flexibility, each bank can
be specified to be 8-, 16-, or 32-bits wide. This allows the use
of 8-bit-wide boot ROM options to minimize overall system
cost. The on-chip boot ROM can be used in product
manufacturing to serially download system code into system
FLASH memory. To further minimize system memory
requirements and cost, the ARM Thumb instruction set is
supported, providing for the use of high-speed 32-bit
operations in 16-bit op-codes and yielding industry-leading
code density. shows the Static Memory Interface pin
assignments.
Note:
Pins are multiplexed. See
for
more information.
Table 1. Power Management Pin Assignments
Pin Mnemonic
I/O
Pin Description
BATOK
I
Battery ok input
nEXTPWR
I
External power supply sense
input
nPWRFL
I
Power fail sense input
nBATCHG
I
Battery changed sense input
Table 2. Static Memory Interface Pin Assignments
Pin Mnemonic
I/O
Pin Description
nCS[5:0]
O
Chip select out
A[27:0]
O
Address output
D[31:0]
I/O
Data I/O
nMOE/nSDCAS
(Note)
O
ROM expansion OP enable
nMWE/nSDWE
(Note)
O
ROM expansion write enable
HALFWORD
O
Halfword access select
output
WORD
O
Word access select output
WRITE/nSDRAS
(Note)
O
Transfer direction
