EP7312
High-Performance, Low-Power System on Chip
M6 VDDIO Pad power Digital I/O power, 3.3V
M7 SSITXFR 1 Low I/O DAI/CODEC/SSI2 frame sync
M8 DRIVE[1] 2
High /
Low
I/O PWM drive output
M9 FB[0] I PWM feedback input
M10 COL[0] 1 High O Keyboard scanner column drive
M11 D[27] 1 Low I/O Data I/O
M12 VSSIO Pad ground I/O ground
M13 A[23]/DRA[4] 1 Low O System byte address / SDRAM address
M14 VDDIO Pad power Digital I/O power, 3.3V
M15 A[20]/DRA[7] 1 Low O System byte address / SDRAM address
M16 D[21] 1 Low I/O Data I/O
N1 nEXTFIQ I External fast interrupt input
N2 PE[1]/BOOTSEL[1] 1
Input
‡
I/O GPIO port E / boot mode select
N3 VSSIO Pad ground I/O ground
N4 VDDIO Pad power Digital I/O power, 3.3V
N5 PD[5] 1 Low I/O GPIO port D
N6 PD[2] 1 Low I/O GPIO port D
N7 SSIRXDA I/O DAI/CODEC/SSI2 serial data input
N8 ADCCLK 1 Low O SSI1 ADC serial clock
N9 SMPCLK 1 Low O SSI1 ADC sample clock
N10 COL[2] 1 High O Keyboard scanner column drive
N11 D[29] 1 Low I/O Data I/O
N12 D[26] 1 Low I/O Data I/O
N13 HALFWORD 1 Low O Halfword access select output
N14 VSSIO Pad ground I/O ground
N15 D[22] 1 Low I/O Data I/O
N16 D[23] 1 Low I/O Data I/O
P1 VSSRTC RTC ground Real time clock ground
P2 RTCOUT O Real time clock oscillator output
P3 VSSIO Pad ground I/O ground
P4 VSSIO Pad ground I/O ground
P5 VDDIO Pad power Digital I/O power, 3.3V
P6 VSSIO Pad ground I/O ground
P7 VSSIO Pad ground I/O ground
P8 VDDIO Pad power Digital I/O power, 3.3V
P9 VSSIO Pad ground I/O ground
P10 VDDIO Pad power Digital I/O power, 3.3V
P11 VSSIO Pad ground I/O ground
P12 VSSIO Pad ground I/O ground
P13 VDDIO Pad power Digital I/O power
P14 VSSIO Pad ground I/O ground
P15 D[24] 1 Low I/O Data I/O
P16 VDDIO Pad power Digital I/O power, 3.3V
R1 RTCIN I/O Real time clock oscillator input
R2 VDDIO Pad power Digital I/O power, 3.3V
R3 PD[4] 1 Low I/O GPIO port D
R4 PD[1] 1 Low I/O GPIO port D
Table 21. 256-Ball PBGA Ball Listing (Continued)
Ball Location Name
Strength
† Reset
State
Type Description
