7. ORDERING INFORMATION

8. REVISION HISTORY

Release

Changes

F1

Final Release

F2

-Updated Thermal Pad pin description in

“QFN Pin Descriptions” on page 7

.

-Updated

“Power Supply, Grounding, and PCB Layout” on page 23

.

F3

-Added “Gain Error” to

“Performance Specifications” on page 10

.

-Added group delay specification for Bypass Mode to

“Digital Filter Characteristics” on page 11

.

F4

Corrected 8.75 ms to 87.5 ms in “The SRC takes some time to make this calculation,
approximately 4200/Fso (87.5 ms at Fso of 48 kHz).” in

Section 4.3.2 SRC Locking and Varispeed

F5

Added -40° to +105°C Automotive grade to feature list on page

23

.

Added Ambient Operating Temperature entry for ‘-EZ’ and ‘-ENZ’ in

“Specified Operating Conditions” on page 9

.

Added entries for CS8421-EZZ/ENZ and CS8421-EZZR/ENZR in

“Ordering Information” on page 35

.

F6

Added note regarding the SDOUT pin in

Figure 5

and

Figure 6

.

Product

Description

Package

Pb-Free

Temp Range

Container

Order#

CS8421

32-bit Asynchronous Sample Rate

Converter

20-TSSOP

YES

-10° to +70°C

Rail

CS8421-CZZ

Tape and Reel

CS8421-CZZR

20-QFN

Rail

CS8421-CNZ

Tape and Reel

CS8421-CNZR

20-TSSOP

-40° to +85°C

Rail

CS8421-DZZ

Tape and Reel

CS8421-DZZR

20-TSSOP

-40° to +105°C

Rail

CS8421-EZZ

Tape and Reel

CS8421-EZZR

20-QFN

Rail

CS8421-ENZ

Tape and Reel

CS8421-ENZR

CDB8421

Evaluation Board for CS8421

-

-

-

CDB8421

Contacting Cirrus Logic Support

For all product questions and inquiries, contact a Cirrus Logic Sales Representative.
To find the one nearest to you, go to

www.cirrus.com.
